WORK SUPPORTS
YOU CAN COUNT ON OUR EXPERTISE
- Introduction
-
Work Support prevents chatter and deformation caused by cutting load during machining workpiece.
Since it maintains machining accuracy of workpiece and reduces tool vibration, tool life is extended. -
Application
Action Description
Spring Advance
Hydraulic Advance
Model No.
-
-
- 1
- Clamp Type
- CWS = Work Support
-
- 2
- Plunger Diameter
- ex ) 20 = Ø20
-
- 3
- Stroke
- ex ) 12 = 12mm
-
- 4
- Action Type
- 1 = Spring Advance
- 2 = Hydraulic Advance
-
- 5
- Mounting Type
- No Sign = Built-In Type
- FG = Flange Gasket Type
-
- 6
- Plunger Spring
- H = High Force
- L = Low Force
-
